Pneumatic Roller

Pneumatic Roller

  • Max.Operating Weight: 20000-29500kg Rated Power: 92-128kw Compaction Width: 2260-2750mm

Product Features

1.Applied with the synchronizer-equipped transmission specially designed for the large-tonnage roller for XG6201P and XG6261P, enjoying a handy, flexible and reliable transmission gearshift. 2.Applied with the power gearshift transmission with hydraulic converter for XG6262P and XG6301P pneumatic tyred rollers, thus providing high performance in starting and parking buffer. 3.Applied with the special pneumatic tyres to compact the placement. 4.Wobbler mechanism applied for front wheels, making the roller tyre contact the ground uniformly when operating on the uneven ground. 5.The road roller is driven by combination of the drive shaft and the counter shaft. The steering, speed change and reversing can all be done by combination of the drive shaft and counter shaft.

Specification


Description Unit XG6201P XG6261P XG6262P XG6301P
Max. Operating Weight kg 20000 26000 26000 29500
Weight of Counter Weighted Sand kg 7800 10660 10660 14550
Min. Operating Weight kg 11200 14500 14500 19000
Compaction Width mm 2260 2750 2750 2750
Ground Specific Pressure Kpa 200~360 200~360 200~360 300~460
Min. Turning Radius mm 7800 9000 9000 9000
Min. Ground Clearance mm 270 300 300 300
Theoretical Gradeability % 20 20 20 20
Wheelbase mm 3550 3836 3836 3836
Travel Speed I km/h 4(F/R) 3.5(F/R) 3.5~6.5(F/R) 3.5~7(F/R)
II km/h 7.3(F/R) 6.6(F/R) 7~15.5(F/R) 7~16(F/R)
III km/h 16.5(F) 15(F) - -
Engine Brand   Yuchai
       (Cummins)
Cummins Cummins Cummins
Model   YC6B125
       (6BT5.9)
6BT5.9 6BT5.9 6BTA5.9
Rated power kW 92
       (100)
100 100 128
Rated speed rpm 2200 2000 2000 2100
Overall Dimension(L×W×H)   mm 4620×2260×3335 4906×2800×3330 4906×2800×3330 4906×2800×3330
