1.Structural painting is used to highlight the shape, waist line and color assortment. 2.The boarding platform adopts stainless steel molding which is rust-proof, anti-corrosion, anti-aging, and durable with high strength. 3.The round arc rearview mirror is used to realize 180° of view. It is good looking and with higher safety. 4.The oil filler cap is molding with lock added. It is good looking and also can prevent the fuel being stolen. 5.The German brand Mann-Hummel double–element air filter is adopted with 99.85% of filter efficiency and 249.3g/m3 of dust storage ability. 6.The German brand Mann-Hummel oil-water separator is adopted. The whole machine uses LED lighting, the power consumption is 38.5% of normal lights, and it is brighter and gentler with service life 10 times of the normal lights.
| Description | Unit | CPC(D)30 | CPC(D)35 | CPC(D)38 | CPCD50 | |
| XG530-D(T)5 Plus | XG535-D(T)5 Plus | XG538-D(T)5 Plus | XG550-DT5C | |||
| Performance | Power Type | Diesel | ||||
| Roted load | mm | 3000 | 3500 | 3800 | 5000 | |
| Load centers distance | mm | 500 | ||||
| Lifting height | mm | 3000 | ||||
| Mast tilt angle(F/R) | ° | 6/12 | 7/12 | |||
| Free lifting height | mm | 145 | 150 | |||
| Max.travel speed | Km/h | 20 | 19 | 26 | ||
| Lifting speed at full load | mm/s | 450 | 360 | 470 | ||
| Max.gradeability | % | 20 | ||||
| Dimensions | Min. turning radius | mm | 2400 | 2420 | 2450 | 2850 |
| Min ground clearance | mm | 140 | 170 | |||
| Front overhang | mm | 475 | 480 | 485 | 555 | |
| Length（ With standard fork ） | mm | 3820 | 3865 | 3890 | 4300 | |
| Width | mm | 1220 | 1490 | |||
| Mast height (retracted) | mm | 2100 | 2180 | 2245 | ||
| Overhead guard height | mm | 2150 | 2255 | |||
| Fork（L×W×H） | mm | 1070×125×45 | 1070×125×50 | 1070×150×55 | ||
| Engine | Model | xinchai490 | DEUTZ498 | xichai4102 | ||
| Rated power | Kw | 36.8 | 36.8 | 45 | 60 | |
| Rated speed | r/min | 2500 | 2500 | 2500 | 2200 | |
| Max.torque | Nm | 156 | 156 | 196 | 320 | |
| Max.speed | r/min | 1700-1900 | 1800 | 1400-1700 | ||
| Others | Deadweight | kg | 4270 | 4550 | 4820 | 6900 |
| Hydraulic Oil Tank Volume | L | 70 | 140 | |||
